High Efficiency Single-Station Industrial Cleaning Machine With Hydrocarbon Spray, Drying And Vacuum Functions from Cleaner Manufacturer

1. Product Features:
(1) Eco-Friendly & High Efficiency
Using hydrocarbon solvents, the closed-loop recycling system achieves zero wastewater discharge, complying with international environmental standards.
(2) Integrated Design
Single-station integration of the full process: cleaning, spraying, and drying, saving space and operation time. Suitable for small to medium batch precision cleaning needs.
(3) Vacuum Drying Technology
Negative pressure environment enables rapid solvent vaporization with no residue or oxidation, especially protecting sensitive materials like metals and optical components.
(4) Precision Cleaning Capability
Multi-angle high-pressure spraying combined with a multi-layer filtration system effectively removes contaminants.
(5) Safety & Reliability
Explosion-proof configurations and high flash point solvent design ensure operational safety in flammable and explosive scenarios.
(6) Energy & Cost Saving
Compared with traditional drying, vacuum drying reduces energy consumption, and the high solvent recovery rate lowers long-term usage costs.
(7) Wide Compatibility
Compatible with various materials (metal, ceramic, plastic, etc.), covering high-end industries such as automotive, electronics, medical, and optics.
(8). This product support non-standard custom, can provide design drawings and cleaning program.

 Non-Standard Parts Customization

Tailored solutions for unique components, including:

- Custom cleaning tank dimensions and configurations

- Adjustable process parameters for material-specific requirements

- Bespoke cleaning protocols and equipment designs to meet niche industry needs

2.Product Analysis and Technical Principles

The "single-station" refers to the equipment completing all processes (cleaning → spraying → drying) within a single enclosed chamber, suitable for small to medium batch and high-precision cleaning needs, differentiating it from multi-station assembly line equipment.
Advantages: Small footprint, simple operation, and low maintenance cost.

Hydrocarbon solvents use high-purity hydrocarbons (such as isoparaffins) as cleaning media, featuring:
✅ Environmentally friendly and non-toxic
✅ Strong dissolving power
✅ High flash point.

The spraying technology uses multi-angle high-pressure spraying arms (pressure range typically 3-8 bar, customizable with variable frequency control) for impact cleaning of workpieces. Combined with a multi-layer filtration system, the solvent is recycled to extend service life.

Vacuum drying involves evacuating the sealed chamber to reduce the solvent boiling point via negative pressure, enabling rapid vaporization of residual solvent, which is then recovered through condensation.

This achieves:
 Oxidation-free drying (prevents metal rusting)
No water marks (zero damage to precision optical components)
High solvent recovery rate (complies with environmental regulations).

Typical Workflow

- Cleaning Stage: Hydrocarbon solvent immersion or ultrasonic assistance dissolves surface grease, cutting fluids, and other contaminants on workpieces.
- Spray Rinsing: High-pressure spraying removes residual dirt, with optional multi-stage spraying (rough cleaning → precision cleaning).
- Vacuum Drying: Evacuation → solvent vaporization → condensation recovery → workpiece cooling and removal.

1.Quality Control:

We are using hight quality material like Simens, Schneider electrical parts. Our machine is designed by experienced engineer who have designed machines for Foxconn, Cummins and BOSCH. The workers also have years experience building automatical cleaning line. Our QC system is covering from raw material to finishing machine.

2.Professional Experience:

We have worked with many famous brand company and goverment project like Foxconn, Cummins and railway department. We also have years international experience with installating and testing machine in other country. We will provide full service for our customer after purchasing.

3.Payment Term:

We can accept flexible payment term due to different situation like 10~20% payment after installation and test service.

We also need some support from you in some case.

4.After Sales Service:

We will provide installation and test service for automatical cleaning line at your facility until cleaning is working properly.

And we offer 1 years with 24/7 work during warranty period.

5.Non-standard customization

We are the source of cleaning machine manufacturers, can help customers customize various types of non-standard cleaning machine, fast delivery.

Customer 's Feedback

Honors and certificates

Please note:

All photos on this site are real. Due to changes in lighting, shooting Angle, and display resolution, the image you see may have some degree of chromatic aberration. GuangDong Blue Whale Clean is a professional Ultrasonic Cleaner manufacturer with 20 years of history in GongDong,China. Our products are updated and upgraded every year.
If you are interested in this product and want to know more details, please contact us on line or E-mail

michael@bwhalesonic.com to us, we will have professional salesman team service for you.

Thank you for your time.
